  • JL Audio 12W0V3-4 12" 600w Car Subwoofer
  • JL Audio 12W0V3-4 12" 600w Car Subwoofer

JL Audio 12W0V3-4 12" 600w Car Subwoofer

Product Code : 12W0V34

List Price: $249.00 On Sale: $228.85 (GST Included) (You save 8.09%)

Warranty Terms & Conditions

$9.95 Flat Rate Generally ships out in 24 to 48 hours.

Availability:

Product Info

Product Info

JL Audio 12W0V3-4 12" 600w Car Subwoofer

We Think YOU Should Know

  • 12 Month JL Audio Australian Warranty
  • Risk Free Purchase Guarantee (bottom of page)
  • 300 watts RMS
  • 4 Ohms
  • 12" Subwoofer

W0v3 Subwoofer Drivers
The term “overbuilt” gets thrown around a lot, but in the case of the W0v3's, it actually applies.

With beefy 2.0 or 2.5-inch voice coils and our patented Elevated Frame Cooling, they're certainly capable of handling power. They also offer best-in-class excursion capability, with motors refined using our exclusive DMA modeling system for increased output and better sound quality.

 The W0v3's incorporate a new terminal and a lead-wire system woven into the spider, along with a new metallic silver frame finish that looks great in any installation.

When the going gets loud, the W0v3's are built to perform like no other woofers in their price class, making them ideal for those seeking high performance from an affordable subwoofer system.

DMA Optimized Motor System
Highly optimized motor system delivers linear motor force over a wide range of excursion and power levels to reduce distortion. more info...

Elevated Frame-Cooling
(U.S. Patent #6,219,431)
Creates a pathway for high-velocity air to flow directly across the top-plate and onto the voice coil. more info...

Most Real Excursion in its Class
The W0v3's offer more linear excursion than our original W6 subwoofers, at less than half the price!

What does this mean for you?
- Louder Bass!
- Less Distortion!

Insanely Great Bass in Small Enclosures!
For maximum application flexibility, W0v3's are designed for use in compact sealed or medium-size ported enclosures.

10W0v3: 0.65 cu.ft. sealed
12W0v3: 1.375 cu.ft. sealed
15W0v3: 1.75 cu.ft. sealed

The Story of "MO"
He's back after all these years... our iconic "bass-face" character first debuted in the original JL Audio Reference Manual to denote subwoofer systems capable of making you look just like him.



Peace of Mind Purchase Guarantee & Declaration of Warranty
This product is supplied directly via JL Audio Australia and enjoys the FULL benefits of the 'JL Audio Australian Warranty'. (You may also be entitled to other consumer warranties as provided by the Australian Consumer Guarantee and these entitlements are not limited by this warranty). In the event that this product should fail please contact our service department to arrange service for this product or you also have the option of speaking with JL Audio Australia directly.

We are a FULLY AUTHORISED Australian retailer for JL Audio Australia.

This product will be shipped from our Sydney Warehouse and you are welcome to pick it up directly from our store in Sydney. This product is NOT DROP SHIPPED from overseas.

Tech Specs

Technical Specifications


12W0v3 DRIVER SPECIFICATIONS

12W0v3-4

Free Air Resonance (Fs): 28.43 Hz
Electrical “Q” (Qes): 0.715
Mechanical “Q” (Qms): 10.709
Total Speaker “Q” (Qts): 0.670
Equivalent Compliance (Vas): 2.530 cu. ft. / 71.64 liters
One-Way, Linear Excursion (Xmax)*: 0.45 in. / 11.4 mm
Reference Efficiency (no): 0.221%
Efficiency (1W/1m)**: 85.64 dB SPL
Effective Piston Area (Sd): 74.509 sq. in. / 0.0481 sq. m.
DC Resistance (Re): 4.280 ohm
Nominal Impedance (Znom): 4 ohm
Thermal Power Handling (Pt): 300W
Driver Displacement: 0.048 cu. ft. / 1.36 liters
Net Weight: 8.11 lbs. / 3.68 kg

* Xmax specifications are derived via one-way voice coil overhang method with no correction factors applied.
** Efficiency (1W/1m) is not an accurate indicator of a subwoofer's output capability and should not be used as a comparison to other subwoofers to determine which one is "louder".

In The Box

What's Included?

  • JL Audio 12W0V3-4 12" 600w Car Subwoofer
